zaiphirionOn to the next milestone of my z80 based computer. The screen...
#Z80 #RetroComputing #HomebrewComputer #8Bit #Electronics #DIYElectronics
Installed the 4MHz oscillator, added independent power and reset controls for both Z80s, and upgraded the variable clock with a new speed control. One step closer to a complete development system.
#Z80 #RetroComputing #HomebrewComputer #8Bit #Electronics #DIYElectronics
#Z80 #RetroComputing #HomebrewComputer #8Bit #Electronics #DIYElectronics
Working on the power and reset circuitry for my custom Z80 computer. One step closer to bringing this machine to life.
#Z80 #RetroComputing #HomebrewComputer #Electronics #DIYElectronics #VintageComputing
Lieven - DF1CNI finally received my power supply breakout PCBs. Only an idiot would forget to mark the positive and negative output. 🫣
#diyelectronics
#diyelectronics
TechTinkTronicsRestoring an old electronic device. The belts are still good, everything rotates freely. No mechanical jams here, ready for more tapes!
Tap that Like, Share, and Subscribe! Visit us on Instagram, TikTok, YouTube and Rumble!
#ElectronicsRepair #VintageTech #DIYElectronics #TechRestoration #CassetteDeck #ReelToReel #AudioRepair #RetroTech
mirobo technologyIt's mirobo Monday!!
I've slowly been working away on some QWIIC things (see what I did there? 😉)!
I made my robots a tiny little VL53L4CD ToF distance sensor module. 🤖
And, I made a matching QWIIC adapter for other I2C devices.
Find them on @PCBWay: https://www.pcbway.com/project/member/shareproject/?bmbno=CFD50F93-D0EC-45
Got a cheap 3018 kit for #diyelectronics pcb milling, Y stepper bad but had spare creality 3dp stepper. No limit/home switches but grbl board so added some. Set up grbl, axis directions and spindle rpm scaling in grbl and bCNC in Linux.
Mounted #3dprinted pcb vice in PLA printed 10+ years ago on my printrbot.
Didnt autolevel, set Z workheight with cigarette rolling paper, and top corner 0.15-0.20mm out.
Came out ok for 1st try. Now autolevelling, pcb vice from alu & beaglebone cnc server.
Mounted #3dprinted pcb vice in PLA printed 10+ years ago on my printrbot.
Didnt autolevel, set Z workheight with cigarette rolling paper, and top corner 0.15-0.20mm out.
Came out ok for 1st try. Now autolevelling, pcb vice from alu & beaglebone cnc server.
Every retro computer project needs a grimoire. Mine is a Zenadi Codex binder packed with pinouts and 74xx logic references.
#RetroComputing #HomebrewComputer #Z80 #Electronics #EmbeddedSystems #ComputerEngineering #Maker #DIYElectronics
#RetroComputing #HomebrewComputer #Z80 #Electronics #EmbeddedSystems #ComputerEngineering #Maker #DIYElectronics
It's freebie Friday!!
I've just shared my new Adapt-2-QWIIC circuit on @PCBWay – it'll pop up after review and join my other shared circuits, here: https://www.pcbway.com/project/member/shareproject/?bmbno=CFD50F93-D0EC-45
Adapt-2-QWIIC is designed to make it easy to connect cheap I2C peripherals using QWIIC cables!
