New on Lectronz: USB LIN Converter https://lectronz.com/products/usb-lin-converter
#CANbus #USB #Equipment

USB LIN Converter

LIN (Local interconnect network) USB Converter (LUC)

🤣😂 Practically, none like CANbus Y, nor Z😅! The nonsense is for You to imagine #mercedesbenz's
Electronic Ignition Switch (N73) act as the Central Gateway (CGW), bridging the different #CANbus's!

https://www.5021.tips/ujanja/benzkey

While "some"🫣 models do (N73), others do (N93), (N54)(Keg🍺) #HapaUjanjatu #teachyourself #ecu #keyprogramming #cartipsandtricks #5021tips #benzrepair #benzkey #smartkeyprogramming

Lectronz May 8

New on Lectronz: CANduino v4 - BreakOut board modul https://lectronz.com/products/canduino-v4-breakout-board
#Arduino #CANbus #Prototyping

CANduino v4 - BreakOut board modul

Breakout board for CANduino v4 with screw terminals for testing projects with CAN bus. Not compatible with CANduino v3, v3.1 & ESP!

Lectronz May 8

New on Lectronz: CANduino v4 - ATmega328P with CAN-bus https://lectronz.com/products/canduino-v4
#Arduino #CANbus #Prototyping

CANduino v4 - ATmega328P with CAN-bus

We sell an Arduino Nano which has an integrated CAN-bus and USB-C. The module has the same size and the same pin arrangement as the Nano.

Lectronz May 6

New on Lectronz: Isolated Dual-CAN Board - Classic CAN 2.0B (3.3V) https://lectronz.com/products/isolated-dual-can-board-classic-can-2-0b-3-3v
#ESP32 #CANbus #Prototyping

Isolated Dual-CAN Board - Classic CAN 2.0B (3.3V)

A robust, industrial-grade 3.3V Dual-CAN interface featuring full galvanic isolation and integrated ESD protection.

Hackaday [Unofficial]May 3

A Tool For Testing CANopen Networks

https://fed.brid.gy/r/https://hackaday.com/2026/05/03/a-tool-for-testing-canopen-networks/

A Tool For Testing CANopen Networks

If you find yourself working with CANopen CC networks, you might find yourself in need of a tool for monitoring what’s happening on the wire. [Michael Fitzmayer] whipped up a piece of softwar…

Hackaday

13 May 3

A Tool For Testing CANopen Networks https://hackaday.com/2026/05/03/a-tool-for-testing-canopen-networks/
#MiscHacks #CAN #Canbus #Canopencc

A Tool For Testing CANopen Networks

If you find yourself working with CANopen CC networks, you might find yourself in need of a tool for monitoring what’s happening on the wire. [Michael Fitzmayer] whipped up a piece of softwar…

Hackaday

5021tips May 2

Imagine #LINbus like some sub-network, connects (abcd) could be, smart sensors, actuators, "minor" #controlunit's, to a major #ECU on a #CANbus🫣!

https://www.5021.tips/ujanja/linbus

Major ECU has 2 stupid resistors, 30k & 1k #ohms #electroniccomponents #repairtips #5021tips #ecurepair #autoelectrical #AutoElectrico #diy #autodiagnostics #CarDiagnostics #AutoWiring

Habr Apr 27

Расширяем OpenPLC с CAN bus

Эта статья является продолжением серии для демо-проекта на базе OpenPLC. В предыдущей части были рассмотрены программирование Raspberry Pi Pico W в режиме Modbus RTU/TCP Slave, управление реле через Ladder-диаграмму. Теперь пришло время добавить в схему CAN-шину. Что добавляется в этой части: узел Pico W получает модуль MCP2515 и подключается к CAN-шине. Для этого в OpenPLC Editor написан пользовательский функциональный блок, который работает поверх ардуино-библиотеки и предоставляет доступ к CAN-шине из обычной Ladder-программы через глобальные переменные-маркеры %MW .

https://habr.com/ru/articles/1028418/

#raspberrypi #openplc #canbus #iec_611313 #diyпроекты

Расширяем OpenPLC с CAN bus

Хабр

5021tips Apr 24

Ujinga wa #obdmode #bootmode #benchmode ni wa muhimu kuzingatiwa, juu #microcontroller (C) ya #ecu hutumia uchawi wa UART kubonga na (H) wa #OBD data ya kupitia (Pini 6/14 kwa #CANbus) ama Pini 7 kwa #kLine

https://www.5021.tips/ujanja/ecudata

Sio lazima uelewe upuuzi wote, download fuata tu maelekezo yalipo #HapaUjanjaTu #autoelectronics #repairtips #5021tips #autorepairtips #magari #dpf #egr #immoff #adblue #autoelectrical #diy
